| WD Blue™ PC Hard Drives |
|
|
| Interface |
SATA 6 Gb/s |
| Formatted Capacity |
2TB / 2000GB |
| Advanced Format (AF) |
Yes/s |
| Form Factor |
3.5-Inch |
| RoHS Compliant |
Yes |
| Performance |
| Data Transfer Rate Max |
|
| Buffer to Host |
6 Gb/s |
| Host to/from Drive (sustained) |
147 MB/s |
| Cache (MB) |
64 |
| Performance Class |
IntelliPower |
| Reliability/Data Integrity |
| Load/Unload Cycles |
300,000 |
| Non-recoverable Read Errors Per Bits Read |
<1 in 10^14 |
| Power Management |
| 12VDC ±10% (A, peak) |
1.73 |
| Average Power Requirements (W) |
|
| Read/Write |
4.1 |
| Idle |
3.0 |
| Standby/Sleep |
0.4 |
| Environmental Specifications |
| Temperature (°C) |
|
| Operating |
0 to 60 |
| Non-operating |
-40 to 70 |
| Shock (Gs) |
|
| Operating (2 ms, read/write) |
30 |
| Operating(2 ms, read) |
65 |
| Non-operating (2 ms) |
250 |
| Acoustics (dBA) |
|
| Idle |
23 |
| Seek (average) |
27 |
| Physical Dimensions |
| Height (in/mm) |
1.028/26.1 |
| Length (in/mm) |
5.787/147 |
| Width (in/mm, ± .01 in) |
4/101.6 |
| Weight(lb/kg, ± 10%) |
1.32/0.60 |
